Flexible on-site production of green hydrogen

Modular PEM electrolyzers
2-50 MW

Reliable and standardized H2 solutions

With FEST electrolysis plants, up to 1,000 kg of high-purity green hydrogen can be produced daily in the space of two 40-foot containers, which is suitable for use in numerous applications for industry or mobility.

Integrated hydrogen production plants: standardized, containerized, modular

Ready to use

The modular
containerized
electrolyser

including power supply, water treatment, transformer, H2 purification and control system.

Advantages of FEST electrolysis systems

Plug-and-play hydrogen electrolyzer

High power density thanks to compact multiple stack design

Fast response times and dynamic operation, ideal for wind and solar

Safe operation at high pressure (up to 34.5 bar(g) without external compression)

Durable, high-performance stacks made in Germany

Effective scaling through 2, 3 or 5 MW module design

Short start and shutdown times, which means load management

Product types

With an electrolysis capacity of 2, 3 or 5 MW, there are various standardized container designs that can be adapted to many requirements thanks to their modularity. In conjunction with our comprehensive range of services, operating costs can be optimized and availability maximized.

Performance data



Rated power
Flow rate Nm3/h
Quality
Size
Control range
Response time
Availability

gEL400

2 MW
400
99.999 % vol (5.0) or DIN EN 17124:2019
2x40' + recooler + 2x chiller
Plug: 20-100%, Bosch: 20-100%, continuous operation and flexible operation
< 1 s load change in the control range per % load change (upwards 1%/s, downwards 5%/s )
>95%

gEL500

2.5 MW
500
99.999 % vol (5.0) or DIN EN 17124:2019
2x40' + recooler + 2x chiller
Plug: 20-100%, Bosch: 20-100%, continuous operation and flexible operation
< 1 s load change in the control range per % load change (upwards 1%/s, downwards 5%/s )
>95%

gEL600

3 MW
600
99.999 % vol (5.0) or DIN EN 17124:2019
2x40' + recooler + 2x chiller
Plug: 20-100%, Bosch: 20-100%, continuous operation and flexible operation
< 1 s load change in the control range per % load change (upwards 1%/s, downwards 5%/s )
>95%

gEL1000

5 MW
1000
99.999 % vol (5.0) or DIN EN 17124:2019
1x40' + 3x20' + transformer + recooler + 3x chiller
Plug: 20-100%, Bosch: 20-100%, continuous operation and flexible operation
< 1 s load change in the control range per % load change (upwards 1%/s, downwards 5%/s )
>95%

gEL1000R

5 MW
1000
99,9 %
1x40' + 2x20' + transformer + 3x chiller
Plug: 20-100%, Bosch: 20-100%, continuous operation and flexible operation
< 1 s load change in the control range per % load change (upwards 1%/s, downwards 5%/s )
>95%

Operating data

PEM electrolyzers

Which version suits your application?

We support you in planning and deciding on the right system configuration and design.

Concepts for larger systems up to 50 MW

With a multiple of the gEL1000, system concepts of up to 50 MW can be realized.
We would be happy to advise you on your individual system concept!

5 MW PEM-Elektrolyseur

gEL1000 (5MW)

1,000 Nm3/h; 90 kg H2/h

2x5 MW PEM Elektrolyseure

gEL2000R* (10MW)

2,000 Nm3/h; 180 kg H2/h

5x10 MW PEM-Elektrolyseure

5x gEL2000R* (50MW)

10,000 Nm3/h; 900 kg H2/h

FEST hydrogen infrastructures

Are you interested in H2 complete systems?

Together with our sister company Maximator Hydrogen, we realize complete hydrogen production and distribution systems.

In addition to the electrolyzer, these also include filling station solutions with integrated compression, storage, cooling and filling of hydrogen.

Our services

Safety concept & HAZOP tested by TĂœV Rheinland (among others)

Complete automation & documentation

Pre-assembly at FEST

Final assembly and commissioning by FEST (or supervision)

CE conformity and declaration

In-house service & maintenance team

Hydrogen from the region - for the region

Decentralized hydrogen production
with PEM electrolysis

With PEM (Proton Exchange Membrane) electrolysis, you can rely on one of the most efficient technologies for hydrogen production. Thanks to its compact design and fast reactivity, the hydrogen electrolyser can convert surplus electricity, for example from renewable energies, directly into high-purity hydrogen.
The high dynamics of this hydrogen electrolyser also enable it to react flexibly to fluctuating energy sources, which makes it particularly suitable for integration into green energy systems. This allows you to produce hydrogen cost-effectively and sustainably – the key technology for a clean future.


Our PEM electrolysers are based on cascadable stacks that each generate up to 200 Nm³/h of hydrogen. The PEM stacks can be regulated between 10 and 100 percent of the nominal output and quickly adapted to load changes. The standardized modular design of our greenelectrolyzer series is ideal for system sizes with nominal loads of up to 50 MW.

PEM Elektrolyse mit Betankungsanlage in der Praxis

This speaks for FEST as the perfect partner

Customized concepts

Our electrolysis systems are based on state-of-the-art technology and offer maximum efficiency in the conversion of water into green hydrogen. This enables particularly cost-effective and environmentally friendly production. We offer flexible solutions that are tailored precisely to the needs of our customers.

Smooth processes through experience

Our team consists of experienced engineers and specialists who not only have extensive knowledge of hydrogen technology, but also decades of experience in the automation of industrial processes. Our customers benefit from this experience at every stage - from planning to operation and maintenance.

Comprehensive services from a single source

The Schmidt-Kranz Group includes companies that have been working with hydrogen for 20 years in the field of compressors and high-pressure components. This allows projects ranging from electrolyzers to complete hydrogen filling stations and storage solutions to be implemented. You benefit from comprehensive and technologically leading solutions.

Best service for the production of green hydrogen

To ensure the best possible performance of your electrolysers, we provide you with a comprehensive service portfolio. Our experts, engineers and consultants offer innovative service solutions that accompany you throughout the entire life cycle of your system – from commissioning to operation and maintenance directly on site.
